CSS Helper MCP

For those that read my Vibe Coding (https://themicrosoftcloudblog.com/2025/11/21/adventures-in-vibe-coding-building-apps-and-tools-without-writing-a-single-line-of-code-introduction/) article you will now that I attempted something that quite frankly I was surprised worked.

To give a brief recap I decided that I would test how good GitHUb Copilot actually was at writing code and creating solutions. So I basically prompted my way to 2 React/Node based solutions, and I didn’t write a single line of code.

However, this was not plain sailing there were certain areas where this approach just did not work well, one of these was CSS. Not so much the creation of sites and CSS implementation, but more troubleshooting and fixing issues, around positioning, cascading, duplication of class names etc. Some of the issues, it would have been quite easy for me to fix, but I was insistent that I would not touch the editor.

After a fruitless session, where I could not get the agent to successfully position a control in the right place on a screen. I wondered if there was a better way. I was already using a few MCP servers in VS Code Sequential-Thinking, Azure MCP etc. So I thought, this may be a good way to approach this problem, so on debugging I could just say the position of control x is incorrect, it should be positioned directly below y, with a 5px padding, and use css-helper to help you diagnose the issue.

Anyway, Copilot (because I was adamant that I would not write code, even for this), designed an MCP server that I could use in this manner, and below is the details of this. The GitHub repo is public so please feel free to take a look and leverage if you decide to do the same weird thing that I did.

https://github.com/richardichogan/css-helper-mcp

CSS Helper MCP Details, Implementation etc.

A Model Context Protocol (MCP) server for CSS debugging with a comprehensive 5-phase investigation protocol.

Features

• 5-Phase Investigation Protocol: Systematic approach to CSS debugging
• CSS Knowledge Base: Built-in solutions for common CSS issues (centering, z-index, flexbox, grid, overflow, etc.)
• Framework-Aware: Understands defaults for Material-UI, Tailwind, Bootstrap, Ant Design, and more
• File System Integration: Search and read CSS/component files in your workspace
• Stateful Investigations: Track findings across multiple phases

Available Tools

Investigation Tools (5-Phase Protocol)

1. css_investigate_start – Initialize a new CSS investigation
   • Returns investigation ID, protocol overview, and relevant CSS knowledge
   • Parameters: issue (description), workspacePath (optional)
2. css_phase1_structure – Phase 1: Structure Analysis
   • Search for components, read files, map hierarchy
   • Parameters: investigationId, componentPattern, workspacePath
3. css_phase2_cascade – Phase 2: Cascade Tracing
   • Search CSS files for matching selectors and rules with specificity analysis
   • Parameters: investigationId, cssPattern, selector, workspacePath
4. css_phase3_conflicts – Phase 3: Conflict Detection
   • Analyze for duplicates, !important usage, specificity issues
   • Parameters: investigationId
5. css_phase4_multilevel – Phase 4: Multi-Level Cascade Analysis
   • Trace how styles combine across levels
   • Parameters: investigationId
6. css_phase4b_browser – Phase 4b: Live Browser Inspection (Optional)
   • Auto-connect to Edge/Chrome DevTools to inspect actual computed styles
   • Automatically captures screenshot of inspected element
   • Parameters: investigationId, elementSelector, chromePort (default: 9222), autoLaunch (default: false)
   • Auto-detects running browser or can auto-launch Edge
7. css_compare_screenshots – Compare Screenshots for Visual Differences
   • Compare expected vs actual screenshots to identify visual differences
   • Uses pixelmatch algorithm to highlight changed pixels
   • Generates diff image showing exact differences in pink
   • Parameters: expectedImage, actualImage, threshold (default: 0.1), investigationId (optional)
   • Returns: Diff percentage, pixel count, and diff image path
8. css_analyze_screenshot – Analyze Screenshot from Prompt for Visual Issues ✨ NEW
   • Paste a screenshot in your prompt and analyze it for CSS problems
   • Detects color contrast issues, invisible elements, bgcolor mismatches
   • Analyzes pixel data to identify light-on-light or dark-on-dark problems
   • Perfect for: “Here’s a screenshot showing the issue – what’s wrong?”
   • Parameters: screenshotPath, investigationId (optional), expectedColors (optional)
   • Returns: Color distribution, dominant colors, detected visual issues, specific fix recommendations
9. css_phase5_solution – Phase 5: Solution Design
   • Generate fix with code and explanation based on static and/or live browser analysis
   • Includes visual diff results if screenshot comparison was performed
   • Parameters: investigationId, originalIssue

Utility Tools

10. css_search_files – Search for CSS/SCSS/LESS files
    • Parameters: pattern (glob), workspacePath

11. css_read_component – Read component file contents
    • Parameters: filePath

12. css_get_knowledge – Query CSS knowledge base
    • Parameters: query (e.g., “centering”, “flexbox”, “z-index”)

Edge/Chrome DevTools Integration (Optional)

For Phase 4b live browser inspection, Edge or Chrome can be used:

Option 1: Manual Launch (Recommended)

# Edge (recommended for Windows)
msedge.exe --remote-debugging-port=9222

# Chrome
chrome.exe --remote-debugging-port=9222

Option 2: Auto-Launch Set autoLaunch: true when calling css_phase4b_browser – it will automatically start Edge if not already running.

Why use Phase 4b?

• Static analysis predicts cascade behavior, but JavaScript, timing, and browser quirks can change the outcome
• Phase 4b connects to Chrome DevTools Protocol to fetch actual computed styles
• Compares static predictions vs browser reality
• Generates fixes based on truth, not guesses

When to skip Phase 4b:

• Simple CSS-only issues without JavaScript interaction
• Quick static analysis sufficient
• Chrome debugging not available/desired

Installation

npm install
npm run build

Configuration

Add to your workspace’s .vscode/mcp.json:

{
  "mcpServers": {
    "css-helper": {
      "command": "node",
      "args": [
        "c:\\Users\\RichardHogan\\Development\\CSS-Helper MCP\\build\\index.js"
      ],
      "type": "stdio"
    }
  }
}

Important:

• Replace the path with your actual installation path
• VS Code MCP configuration is workspace-specific – copy this to each project’s .vscode/mcp.json

Usage with GitHub Copilot

Once configured, use the CSS Helper via GitHub Copilot Chat:

@workspace Use css_investigate_start to debug: "Button not centered in container"

Follow the 5-phase protocol to systematically diagnose and fix CSS issues.

Example Investigation Flow

Basic Flow (Static Analysis Only)

1. Start: Use css_investigate_start with issue description
2. Structure: Use css_phase1_structure with component pattern (e.g., **/*Button*.tsx)
3. Cascade: Use css_phase2_cascade with CSS pattern (e.g., **/*.css) and selector (e.g., .button)
   • Now includes CSS specificity calculation and cascade prediction
4. Conflicts: Use css_phase3_conflicts to detect issues
5. Analysis: Use css_phase4_multilevel for cascade layers
6. Solution: Use css_phase5_solution to get the fix

Enhanced Flow (With Live Browser Inspection + Screenshot Comparison)

Option A: Manual Browser Launch

1. Start Edge with debugging: msedge.exe --remote-debugging-port=9222
2. Open your webpage in that Edge instance
3. Run phases 1-4 as normal
4. Add Phase 4b: Use css_phase4b_browser with elementSelector (e.g., .button, #header)
   • Automatically captures screenshot of the element
5. Compare screenshots (optional): Use css_compare_screenshots with baseline and captured screenshot
   • Shows exact pixel differences and generates diff image
6. Generate solution: Use css_phase5_solution
   • Includes visual diff data if comparison was performed

Option B: Fully Automated (Zero Manual Steps)

1. Run phases 1-4 as normal
2. Add Phase 4b: Use css_phase4b_browser with elementSelector and autoLaunch: true
   • Automatically launches Edge if not running
   • Fetches actual computed styles from browser
   • Captures screenshot automatically
   • Compares static predictions vs reality
3. Compare with baseline (optional): Use css_compare_screenshots to verify visual accuracy
   • Highlights pixel-level differences
   • Quantifies visual regression
4. Generate solution: Use css_phase5_solution
   • Now uses browser data for accurate fixes
   • Shows “Static predicted X but browser applied Y” insights
   • Includes visual diff percentage if screenshots were compared

Screenshot Comparison

The css_compare_screenshots tool uses the pixelmatch algorithm to identify visual differences:

Features:

• Pixel-perfect comparison between expected and actual screenshots
• Adjustable threshold (0-1, default 0.1) for match sensitivity
• Generates diff image highlighting changed pixels in pink
• Returns percentage of different pixels
• Automatically stored in investigation if investigationId provided

Example Usage:

Use css_compare_screenshots with:
- expectedImage: "path/to/baseline.png"
- actualImage: ".css-helper-screenshots/investigation-123-timestamp.png"
- threshold: 0.1 (optional)
- investigationId: "investigation-123" (optional)

Output:

• Diff percentage (e.g., “2.34% different”)
• Changed pixel count
• Diff image path showing exact differences
• Status: ✅ (<1%), ⚠️ (1-5%), or ❌ (>5%)

Screenshot Analysis ✨ NEW

The css_analyze_screenshot tool analyzes a single screenshot for visual CSS issues:

Use Case: “Here’s a screenshot showing the problem – what’s wrong with the CSS?”

Features:

• Analyzes pixel color distribution (white, black, grey percentages)
• Identifies dominant colors in the screenshot
• Detects visual issues:
  • Light-on-light elements (bgcolor=’grey.50′ in light containers)
  • Dark theme with unthemed light components
  • Poor contrast or washed-out appearance
  • Expected vs actual color scheme mismatches
• Provides specific Material-UI fix recommendations

Example Usage:

Attach a screenshot to your prompt, then:

Use css_analyze_screenshot with:
- screenshotPath: "path/to/screenshot.png"
- expectedColors: { background: "dark", text: "white" }
- investigationId: "investigation-123" (optional)

Output:

• Color distribution percentages
• Top 5 dominant colors
• Detected visual issues with severity
• Specific fix recommendations (e.g., “Replace bgcolor=’grey.50′ with bgcolor=’background.paper'”)
• Material-UI code examples

Why This is Better:

• ✅ No browser DevTools connection needed
• ✅ Works with any screenshot (design mockups, production, user-submitted)
• ✅ Instant analysis without running the app
• ✅ Perfect for: “I pasted a screenshot, tell me what’s wrong”

CSS Knowledge Base

The server includes solutions for:

• Centering: Flexbox, Grid, and absolute positioning approaches
• Z-Index: Stacking context and positioning issues
• Flexbox: Wrap, flex-basis, and min-width problems
• Grid: Template columns, auto-fit, and minmax issues
• Overflow: Text wrapping and scrollable containers
• Specificity: Selector hierarchy and !important usage
• Positioning: Relative, absolute, fixed, and sticky
• Responsive: Media queries and fluid layouts

Testing

MCP Inspector (Quick Test)

npx @modelcontextprotocol/inspector node "c:\Users\RichardHogan\Development\CSS-Helper MCP\build\index.js"

Look for:

• Green “Running” indicator
• All 12 tools listed (updated from 9)
• Server name “css-helper” version “1.0.0”

VS Code with ACRE Project

1. Copy .vscode/mcp.json to your ACRE project
2. Restart VS Code
3. Use GitHub Copilot Chat with @workspace to access tools

Development

npm run build    # Compile TypeScript
npm run prepare  # Pre-commit build hook

Troubleshooting

Server not showing in VS Code:

• Verify .vscode/mcp.json exists with correct path
• Restart VS Code after configuration changes
• Check VS Code MCP panel for connection status

Module errors:

• Run npm install to ensure dependencies are installed
• Check build/index.js exists after npm run build
